VSI Vertical Shaft Impact Crusher
2025年2月17日
Hydraulic roller crusher
2025年2月17日VSI Vertical Shaft Impact Crusher
2025年2月17日Hydraulic roller crusher
2025年2月17日50 - 550 t/h
Capacity
20 mm
Min. Output Size
80 mm
Max. Input Size
Highlights
High Efficiency Performance
The VSI crusher achieves superior efficiency due to its advanced impact mechanism and precise control over material flow.
Adaptive Design for Versatility
Its reversible design allows for easy adjustment and flexibility in handling various materials, making it suitable for diverse industrial applications.
Rugged
Built with high-quality components, the SHKX crusher is designed to withstand harsh operating conditions, ensuring long-term reliability and performance.
Cost-Effective Maintenance
The SHKX features a user-friendly structure that simplifies maintenance tasks, reducing downtime and lowering overall operational costs.
Working Principle
1
Reversible Breaking Mechanism
The SHKX crusher features a unique reversible breaking mechanism that allows it to alter the direction of the crushing process, adapting to various material properties and ensuring efficient particle size reduction.
2
High-Efficiency Crushing
Utilizing advanced technology, the SHKX achieves high efficiency in breaking down materials with minimal energy consumption, making it ideal for large-scale operations.
3
Intelligent Control System
Equipped with sensors and a sophisticated control system, the crusher monitors and adjusts the crushing process in real-time, optimizing performance and ensuring consistent output quality.
4
Durable Material Construction
Constructed from high-quality, wear-resistant materials, the SHKX ensures extended service life even under demanding conditions, reducing maintenance frequency and costs.
5
Low Noise Operation
The design incorporates noise-reducing features, providing a quieter operation environment, which is particularly beneficial in urban or residential areas where noise pollution is a concern.
6
Easy Maintenance Design
Designed with user-friendly accessibility, the SHKX facilitates routine maintenance and component replacement, minimizing downtime and enhancing overall operational efficiency.
Gallery
Technical Specs
| Model | SHKX-950 | SHKX-1200 | SHKX-1600 | SHKX-2000 |
|---|---|---|---|---|
| Rotor Diameter(mm) | 950mm | 1200mm | 1600mm | 2000mm |
| Rotor Length(mm) | 1200mm | 1600mm | 2000mm | 2600mm |
| Max Feeding Size | <80mm | <80mm | <80mm | <80mm |
| Discharge Size | ≤5mm | ≤5mm | ≤5mm | ≤5mm |
| Max Material Moisture | <15% | <15% | <15% | <15% |
| Capacity | 50-100T/H | 100-200 T/H | 200-380T/H | 380-550T/H |
| Hammer Line Speed | 56m/s | 62m/s | 62m/s | 70m/s |
| Power | 90-110kw | 250-315kw | 560-630kw | 800kw |
| Rotate Speed | 990r/min | 980r/min | 740r/min | 740r/min |
| Voltage | 380v | 380V | 6000v | 6000v |
| ( 10000v ) | ( 10000v ) | |||
| Hydraulic Coupler | YOX600 | YOX1000 | YOX1150 | YOX1250 |
FAQ
If you encounter any problems while using our crushers, sand makers, grinding mills or mobile crushers and other mining equipment, or have any questions about equipment selection, operation and maintenance, troubleshooting, etc., you are welcome to leave a message here for consultation.
Job Position
Comments from Engineers
1What causes excessive vibration in the SHKX reversible fine crusher?
Excessive vibration can be caused by improper installation, imbalance in rotating parts, or feeding uneven material. Ensure proper alignment and balance during setup, and avoid feeding oversized or non-uniform materials.
2Why is there a loud noise coming from the crusher during operation?
Loud noises may indicate worn-out components (e.g., jaw plates or bearings) or improper lubrication. Regular maintenance and inspection of wear parts can help prevent this issue.
3How to improve the output efficiency of the SHKX reversible fine crusher?
Adjust the feed size to match the crusher’s capacity, ensure proper lubrication, and avoid overloading the equipment. Additionally, regular maintenance can help maintain optimal performance.
4What is the recommended frequency for replacing worn-out parts in the SHKX crusher?
The frequency of wear part replacement depends on the material being crushed and operating conditions. Typically, it is advisable to inspect components regularly and replace them when wear reaches 60-70% of their original thickness.
5Why does the crusher’s output particle size not meet specifications?
This can occur due to improper adjustment of the discharge opening or feeding oversized material. Ensure the discharge setting is correctly adjusted according to the desired product size, and avoid overloading the crusher.
6What type of lubrication should be used for the SHKX reversible fine crusher?
Use high-quality grease or oil that meets the manufacturer’s specifications. Regularly apply lubrication to the rotating parts, such as the eccentric shaft journal and bearings, to ensure smooth operation and reduce wear.
