PE Jaw Crusher
2025年2月10日
PEX Jaw Crusher
2025年2月11日PE Jaw Crusher
2025年2月10日PEX Jaw Crusher
2025年2月11日15 - 650 t/h
Capacity
220 - 930 mm
Max. Feeding Size
Highlights
Efficient Crushing Performance
The PEW Jaw Crusher offers excellent crushing efficiency, capable of handling hard and medium-hard materials with minimal energy consumption. Its robust design ensures consistent output and high productivity.
Long-lasting Structural Design
The machine features a sturdy frame structure optimized for long-term durability. This reduces maintenance costs and operational downtime, making it an ideal choice for demanding industrial applications.
Wide Range of Applications
PEW Jaw Crusher is versatile, suitable for various industries such as mining, construction, demolition, and recycling. It can process materials like stone, ore, and non-metallic minerals effectively.
Easy maintenance
The machine includes a maintenance-friendly design with easy access parts and spare components, simplifying repair and replacement processes. This minimizes operational interruptions and extends the equipment's lifespan.
Working Principle
1
Mechanical Impact
The jaw crusher uses the impact between two jaws (fixed and movable) to crush the material into smaller pieces.
2
Pressure Application
The machine applies enormous pressure on the material between the two jaws, causing it to break apart.
3
Friction Force
Friction between the moving parts of the jaw crusher plays a significant role in breaking down the material by creating stress on its surfaces.
4
Centrifugal Force Utilization
The rotation of the jaw crusher's components generates centrifugal force, which aids in separating and crushing the material.
5
Hydraulic Assistance
Water is sometimes used as a supplementary medium to enhance the crushing process, particularly for tough materials.
6
Energy Transfer
The entire operation relies on the transfer of mechanical energy from the motor or other power source to the jaw components, enabling the breaking down of hard materials.
Gallery
Technical Specs
| Model | Feed Opening Size (mm) | Max. Feeding Size (mm) | Adjustable Range of Output Size (mm) | Capacity (t/h) | Speed (r/min) | Motor Power (kw) | Overall Dimension (mm) |
|---|---|---|---|---|---|---|---|
| PEW250×1000 | 250×1000 | 220 | 20-40 | 15-50 | 330 | 30 | 1400×1850×1310 |
| PEW250×1200 | 250×1200 | 220 | 20-40 | 20-50 | 330 | 37 | 1400×2050×1310 |
| PEW400×600 | 400×600 | 350 | 35-85 | 15-70 | 250 | 37 | 1920×1460×1840 |
| PEW760 | 760×1100 | 640 | 75-200 | 150-350 | 270 | 110 | 2600×2500×2200 |
| PEW860 | 860×1100 | 720 | 100-225 | 200-500 | 240 | 132 | 3300×2320×3120 |
| PEW1100 | 1100×1200 | 930 | 150-275 | 300-650 | 210 | 185 | 4140×2660×3560 |
FAQ
If you encounter any problems while using our crushers, sand makers, grinding mills or mobile crushers and other mining equipment, or have any questions about equipment selection, operation and maintenance, troubleshooting, etc., you are welcome to leave a message here for consultation.
Job Position
Comments from Engineers
1What is the main purpose of a PEW Jaw Crusher?
The PEW Jaw Crusher is primarily designed for primary and secondary crushing operations, breaking down hard and
medium-hard materials into smaller particles for further processing in industries like mining, construction, and
demolition.
2How does the PEW Jaw Crusher differ from other types of crushers?
It differs due to its robust frame structure, high efficiency, and durability. It is particularly noted for its
ability to handle tough materials while maintaining high productivity rates compared to other crushers like cone
or hammer crushers.
3What are the typical applications of a PEW Jaw Crusher?
The PEW Jaw Crusher is widely used in mining operations for ore extraction, construction for demolishing stone
and concrete, demolition for recycling materials, and aggregate production for building materials.
4What are the key advantages of using a PEW Jaw Crusher?
Key advantages include high crushing efficiency, long-lasting structural design, versatility in handling
various materials, and cost-effectiveness with minimal maintenance requirements.
5How should one maintain a PEW Jaw Crusher to ensure optimal performance?
Proper maintenance involves regular inspections, replacing wear parts like toggle plates or bearings as needed,
lubricating moving components, and ensuring the feed hopper is cleaned regularly to prevent blockages.
